Designed to meet the stringent size, weight & Ripple content requirement of 4 KW, 28v DC electrical supply for underwater application, this consist of a permanent magnet, 3 phase alternator and an Automatic Voltage Regulator (AVR) with internal rectifier filter and a ultra – low ripple output filter.
Delivers 28V DC, 4KW output with 200 mv ripple between 3600 to 6000rpm.
Generator Specifications
| Type of generator | Permanent magnet Brush less, AC |
| Input Speed | 3600-6000 rpm |
| Output Voltage | 3 Phase AC line to line voltage between 30.3 to 49v for all speed and load conditions (to deliver 28V DC when used with AVR) |
| Output Power | 4kW DC (with AVR) |
| Overload capacity | 10% of full load |
| Body temperature output | Through two wire thermister ending in pig tail |
| Cooling | Self cooled |
| Dimensions | 310x88x88mm |
| weight | Less than 8kg |
AVR specifications
| Output voltage | 28±1V DC for all speed and load conditions |
| Output ripple | 200mV p to p |
| Output power | 4kW |
| Over load capacity | 10% of full load |
| Fault output | Over voltage, over Current, Over Speed, Under Voltage ,Generator Body temperature |
| Output voltage setting | Through a trim pot |
| Dimensions | As above |
| Weight | Less than 5kg |
| Cooling | Self cooled |
